>> Information
S600-C is an integrated multi-parameter water quality instrument used for online long-term monitoring water quality. It can be installed with up to 7 probes, can measure water quality parameters in the field effectively.
S600-C has a special self-cleaning design, wiper components to eliminate bubbles and prevent microbial growth, and can be monitored in various water environments including rivers, lakes, oceans, reservoirs, industrial water and groundwater.
>> Characteristics
Good reliability, can operate in an unattended environment for months without maintenance;
Self-cleaning function, self-cleaning coating film and wiper structure design, ensure the measurement
Window clean, prevent microbial growth, reduce maintenance frequency;
Automatic identification, each probe is digital sensor, easy for replacement;
High degree of integration, can choose sensors with different parameters;
The maintenance frequency is low, requiring only maintenance once every three months, which greatly reduces the maintenance work;
Standard electrode at default ( can be replaced)
Temperature, Conductivity, pH, ORP, Turbidity, Dissolved Oxygen
Optical electrode Options
Total Suspended Solid, Chlorophyll, Blue Green Algae, COD, Nitrate ion, Ammonium ion, Potassium ion, Fluoride ion, Chloride ion, Calcium ion, CDOM/FDOM, depth and etc.
>> Application
S600-C water probe housing is made of Stainless steel 316, and all the sensors are made by Titanium which is with higher corrosion-resistance. Here are some specific applications:
Surface water sampling and profiling
Long-term water monitoring
Sea water, estuary monitoring
Industrial water system, Municipal water system
>> Parameters
Specification | Details |
Size | φ88mm*548mm ( length) |
Weight | 2.5KG |
Main Material | POM+316 Stainless Steel |
O ring: viton ring+ rubber ring | |
Cable: PVC | |
Waterproof Rate | IP68 |
Measuring parameters | Standard: Temperature, Conductivity, pH, Turbidity, Dissolved Oxygen |
Optional: Depth, ORP, Chlorophyll, Blue-green Algae, NH4+, K+, TSS, Salinity and etc. | |
Data Output | RS 485. Modbus; Bluetooth(Optional) |
Internal Storage | 8M (Optional) |
Power | DC 12~24V |
Storage Temperature | -20~+60℃(pH/ORP storage temperature 0~60℃) |
Working Temperature | 0~50℃ |
Pressure Range | Sensor Probe ≤0.6Mpa; Sensor Body≤2Mpa |
Cable Length | 5m standard cable, other length can be optional; |
Guarantee Period | Sensor Body 12 months; pH/ORP probe 12 months; |
Ion sensor: 6 months; DO membrane cap 6 months. |
Conductivity | |
Measuring principle | Four-electrode method |
Measuring range | 0-200mS/cm |
Measuring accuracy | 0-100: reading value±0.5% |
100-200: reading value±1% | |
Resolution | 1μS/cm-100μS/cm (according to the range) |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
Calibration way | one or two point calibration |
Temperature | |
Measuring principle | Thermistor method |
Measuring range | 0-50℃ |
Measuring accuracy | ±0.2℃ |
Resolution | 0.1℃ |
Working temperature | -5C~+50℃ |
Storage Temperature | -20C~+80℃ |
Calibration way | one point calibration |
pH | |
Measuring principle | Electrode method |
Measuring range | 0-14 |
Measuring accuracy | ±0.1 |
Resolution | 0.01 |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | 0-60℃ |
Calibration way | two or three point calibration |
ORP | |
Measuring principle | Electrode method |
Measuring range | -1999~+1999mV |
Measuring accuracy | ±20mV ( standard solution) |
Resolution | ±0.1mV |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | 0-60℃ |
Calibration way | one point calibration |
Turbidity | |
Measuring principle | Scattered light measurement |
Measuring range | 0.01-4000NTU |
Measuring accuracy | 0-10NTU: ±0.1NTU |
10-100NTU: reading value±2% or ±0.1NTU the bigger one; | |
100-4000NTU: reading value±5% | |
Resolution | 0-10NTU: 0.01NTU |
10-100NTU: 0.1NTU | |
100-4000NTU: 1NTU | |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | -20C~-60℃ |
Calibration way | one or two point calibration |
Dissolved Oxygen | |
Measuring principle | Fluorescence method |
Measuring range | 0-200% saturability 0-20mg/L |
Measuring accuracy | 0-100%: <±1% |
100-200%: <±1.5% | |
Resolution | 0.001mg/L-0.01mg/L (according to the range) |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
Calibration way | one or two point calibration |
Depth | |
Measuring principle | Pressure sensitive method |
Measuring range | 200m ( effective measurement depth of the electrodes is 60m) |
Measuring accuracy | <±0.05 %F.S |
Resolution | 0.001m |
Calibration way | one point calibration |
Chlorophyll | |
Measuring principle | Fluorescence method |
Measuring range | 0-400ug/L or 0~100RFU |
Linearity | R²>0.999 |
Resolution | 0.01ug/L |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
Calibration way | one or two point calibration |
Blue-Green Algae | |
Measuring principle | Fluorescence method |
Measuring range | 0-100ug/L or 0~100RFU |
Linearity | R²>0.999 |
Resolution | 0.01ug/L |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
Calibration way | one or two point calibration |
COD | |
Measuring principle | Spectrophotometric ultraviolet absorption |
Measuring range | 0.1~200mg/L ( equiv. KHP) |
Linearity | ±2% or 0.5 mg/L take the bigger(equiv. KHP) |
Resolution | 0.1mg/L (equiv. KHP) |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
Calibration way | one or two point calibration |
NH4+ | |
Measuring principle | Composite ion electrode method |
Measuring range | 0~10/100/1000mg/L for option |
Linearity | 10% or ±0.2mg/L take the bigger |
Resolution | 0.01mg/L-0.1mg/L (according to the range) |
Temperature compensation | Yes |
Working temperature | 0-50℃ |
Storage Temperature | -20C~+60℃ |
